Description

Type: 3-speed, fully manual operation

Motor: DC servo motor

Drive Method: Direct drive

Speeds: 33-1/3 RPM, 45 RPM, 78 RPM

Turntable Platter: Die-cast aluminum

Starting Torque: >1.0 kgf.cm

Braking System: Electronic brake

Wow and Flutter: <0.2% (WTD) @ 3 kHz (JIS)

Signal-to-Noise Ratio: >50 dB

Output Level: Pre-amp “PHONO”: 4 mV nominal at 1 kHz, 5 cm/sec / Pre-amp “LINE”: 240 mV nominal at 1 kHz, 5 cm/sec

Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized

USB Function: A/D, D/A – 16-bit/44.1 kHz or 48 kHz USB selectable; Computer interface – USB 2.0 Compliant Windows 7 or above, or MAC OS X or above

Power Supply Requirements: 100 to 240 V, 50/60 Hz, 1.5A Max

Power Consumption: 2.75 W

Dimensions: 452.0 mm (17.80″) W x 352.0 mm (13.86″) D x 141.6 mm (5.57″) H

Weight: 8 kg (17.6 lbs.), without dust cover

Accessories Included: AT-VM95E phono cartridge; AT-HS6 headshell; 1.9 m (6.2′) USB cable; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; felt mat; dust cover; 45 RPM adapter; plug-type stylus target light

Tonearm Type: Balanced S-shaped tonearm with detachable headshell

Effective Arm Length: 230.5 mm

Overhang: 16 mm

Tracking Error Angle: Less than 3 degrees

Applicable Cartridge Weight: 3.5-8.5 g

Anti-skating Range: 0-4 g

Replacement Stylus: AT-VMN95E

Communication System: Bluetooth Version 5.0

Maximum Communication Range: Line of sight – approx. 10 m (33′)

Compatible Bluetooth Profile: A2DP

Support Codec: SBC, Qualcomm® aptX™ audio
