Description

Fully automatic belt-drive turntable operation with two speeds: 33-1/3, 45 RPM

Balanced straight tone arm with hydraulically damped lift control and rest

Built-in switchable phono/line pre-amplifier with attached dual RCA output cable

Switchable pre-amp modes for moving magnet and moving coil cartridges

½” mount universal headshell with AT91R Dual Moving Magnet phono cartridge and long-life diamond stylus

Anti-resonance, die-cast aluminum platter with 4 mm thick rubber mat

Damped base construction for reduced low-frequency feedback coloration

Includes 45 RPM adapter and removable hinged dust cover

Type: Belt-drive turntable, fully automatic

Motor: DC servo-controlled

Speeds: 33-1/3 RPM, 45 RPM

Turntable Platter: Die-cast aluminum

Wow and Flutter: Less than 0.25% (WTD) @ 3 kHz (JIS)

Signal-to-Noise Ratio: >50 dB (DIN-B)

Output Level: Pre-amp “PHONO”: 1.5-3.6 mV nominal at 1 kHz, 5 cm/sec _ Pre-amp “LINE” 129-313 mV nominal at 1 kHz, 5 cm/sec

Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized

Power Supply Requirements: 120V AC, 60 Hz

Dimensions: 434.0 mm (17.1″) W x 128.0 mm (5.0″) H x 350.0 mm (13.8″) D

Weight: 5.2 kg (11.5 lbs.)

Accessories Included: AT91R Dual Moving Magnet stereo cartridge with replaceable stylus; 1/2″ mount universal headshell; power cord; 45 RPM adapter; removable hinged dust cover; 4 mm rubber mat

Notes: Replacement Stylus: ATN91R
