Motor: DC motor
Drive Method: Belt-drive
Speeds: 33-1/3 RPM, 45 RPM
Turntable Platter: Die-cast aluminum
Wow and Flutter: < 0.25% (WTD)
Signal-to-Noise Ratio: > 55 dB
Cartridge Type: This product is equipped with an AT-VM95C Dual Moving Magnet Stereo Cartridge. The cartridge cannot be removed.
Output Level:
PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec
LINE: 252 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized
Power Consumption: 1.6 W
Dimensions: 400 mm (16″) × 330 mm (13″) × 110 mm (4.3″) (W × D × H)
Weight: Approx. 2.9 kg (6.4 lbs)
Accessories Included
• Dust cover
• Felt mat
• Platter (with drive belt)
• Dust cover hinges
• 45 RPM adapter
• RCA audio cable (Approx. 1.0 m (3.3′))
• AC adapter (Approx. 1.5 m (4.9′))
AC Adapter *Type: FJ-SW1261200500DN
Rated Input Voltage: 100 to 240 V AC
Rated Input Current: 0.4 A max.
Rated Frequency: 50 Hz / 60 Hz
Rated Output Voltage: 12 V DC
Rated Secondary Current: 0.5 A
Cable Length: Approx. 1.5m (4.9′)
Effective Arm Length 220 mm (8.7″)
Overhang 18 mm (0.71″)
Tracking Error Angle Less than 2.0°
Replacement Stylus AT-VMN95C (sold separately)
Replacement Belt AT-LP70X exclusive belt (sold separately)
Communication System Bluetooth version 5.2
Frequency Band 2.402 GHz to 2.480 GHz
Maximum RF Output 2.5 mW EIRP
Maximum Communication Range Line of sight – approx. 10 m (33′)
Modulation Method GFSK, Pi/4DQPSK, 8DPSK
Compatible Bluetooth Profile A2DP
Support Codec Qualcomm® aptX™ Adaptive audio, Qualcomm® aptX™ audio, SBC
Notes *The included AC adapter may differ depending on the country of sale. Check the rating label on the AC adapter. For details, contact your local Audio-Technica dealer.
For product improvement, the product is subject to modification without notice.
