Description
Description
The Cudy Passive Gigabit PoE Injector (POE48-24W) — model POE48-24W — is designed to deliver both power and data over a single Ethernet cable for PoE-enabled devices such as IP cameras and access points. It supports 10/100 Mbps data rates and provides up to 24 W of power per user port, allowing flexible device placement without separate power adapters.
Tech Specs
| Passing Data Rate | 10/100 Mbps |
| Power over Ethernet Output | Pin assignment & polarity: 1/2 (-), 3/6 (+); Output voltage: 54 VDC; User port power: max. 24 W |
| Input Power Requirements | AC input voltage: 100–240 VAC; AC input current: 0.5 A; AC frequency: 50–60 Hz |
| Dimensions | 83.5 mm × 42.8 mm × 30.8 mm |
| Indicators | System indicator: AC power; User indicator: Channel power |
| Connectors | Shielded RJ-45, EIA 568A and 568B |
| Security & Protection | Overcurrent protection, overcharge protection, high voltage protection, interference protection |
| Warranty Terms: | 1‑Year Warranty Provided by 101 Multimedia |
★ ★ ★ ★ ☆
4.2 out of 5
“Reliable passive Gigabit PoE injector with stable 24 W output — perfect for powering IP cameras or access points without extra adapters.”
