Description

Image sensor: 1/2.7” Progressive Scan CMOS

Shutter Speed: Self-adaptive shutter

Lens: 2.8 mm, viewing angle: 106° (Horizontal), 122° (Diagonal) 4 mm, viewing angle: 86° (Horizontal), 102° (Diagonal) 6 mm, viewing angle: 52° (Horizontal), 62° (Diagonal)

DNR: 3D DNR

Lens Mount: M12

Day & Night: IR-cut filter with auto-switching

WDR: WDR

BLC: Supports

Night Vision: Up to 98 ft / 30 m

Max. Resolution: 2304 × 1296

Frame Rate: Max: 25fps; Self-Adaptive during network transmission

Audio Bit Rate: Self-Adaptive

Max. Bitrate: 3Mbps

Video Compression: H.265 / H.264

Video Bit Rate: Ultra-HD; HD; Standard. Adaptive bit rate.

Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth: Support 20MHz

Security: 64/128-bit WEP, WPA/WPA2,

Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps

Wi-Fi Pairing: AP pairing

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wired Network: RJ45 × 1(10M/100M Adaptive Ethernet Port)

Smart Alarm: Motion Detection, AI-Powered Human Shape Detection / Vehicle Shape Detection

Customized Alert Area: Supports

Two-way Talk: Supports

General Function: Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Local Storage: Supports microSD card storage (up to 512 GB)

Cloud Storage: Supports EZVIZ CloudPlay storage

IP Grade: IP67

Operating Conditions: -30℃ ~ 50℃, humidity 95% or less (non-condensing)

Power Supply: DC 12V / 1A

Power Consumption: MAX. 8W

Dimensions: 106 × 106 × 90 mm (4.17 × 4.17 × 3.54 inch)

Weight: 229 g (8.08 oz)
