Description

Image Sensor: 1/2.7″ Progressive Scan CMOS

Shutter Speed: Self-adaptive shutter

Lens: 4mm@ F1.6, view angle:104° (Horizontal), 87° (Vertical), 53°(Diagonal)

PT Angle: Pan: 353° , Tilt: 133°

Minimum Illumination: 0.51Lux @(F1.6, AGC ON), 0 Lux with IR

Lens Mount: M12

Day & Night: IR-cut filter with auto-switching

DNR: 3D DNR

WDR: Digital WDR

BLC: Supports

Night Vision: 10 m

Max. Resolution: 2880 × 1620

Frame Rate: Max:25fps; Self-Adaptive during network transmission

Video Compression: H.265 / H.264

Video Bit Rate: Ultra-HD; HD; Standard. Adaptive bit rate.

Audio Bit Rate: Self-Adaptive

Max. Bitrate: 4 Mbps

Wi-Fi Standard: IEEE802.11a, 802.11b, 802.11g, 802.11n, 802.11ac

Frequency Range: 2.4G: 2400~2483.5 MHz 5G: 5170~5250 MHz，5735~5835 MHz

Channel Bandwidth: Supports 40 MHz

Security: 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

Transmission Rate: 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7; 11a 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7

Wi-Fi Pairing: AP pairing

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Local Storage: Micro SD card slot (Max. 512G)

Cloud Storage: EZVIZ Cloud Storage

Smart Alarm: AI-Powered Human Shape Detection / Pet Detection / Waving-Hand Detection / Voice Activity Detection

Customized Alert Area: Supports

Two-Way Talk: Supports ( Double Mic )

General Function: Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Operating Conditions: -10°C to 45°C ( 14°F to 113 °F ), humidity 95% or less (non-condensing)

Power Supply: DC 5V/2A（Type-C)

Power Consumption: Max. 8W

Product Dimensions: 115.5 × 116 × 160 mm (4.55 × 4.57 × 6.30 inch)

Packaging Dimensions: 116 × 116 × 164 mm (4.57 × 4.57 × 6.46 inch)

Weight (With Package): 487 g (17.18 oz)

Net Weight: 255 g (8.99 oz)
