Resolution Dual: 2K+ Resolution
Image Sensor: 1/3″ Progressive Scan CMOS
Shutter Speed: Self-adaptive shutter
Fixed Lens: [email protected] , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
PT Lens: [email protected] , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
Lens Mount: M12
Day & Night: IR-cut filter with auto-switching
DNR: 3D DNR
WDR Digital: WDR
Video Compression: H.264/H.265
Video Bit Rate: Adaptive bit rate.
Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
Wi-Fi Pairing: AP paring
Protocol: EZVIZ cloud proprietary protocol
Interface Protocol: EZVIZ cloud proprietary protocol
Max. Resolution: 2560 × 1440
Frame Rate: Max:30fps; Self-Adaptive during network transmission
Storage: Micro SD card slot (Max. 512G)
Power: TYPE-C
Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Standard: IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
Frequency Range: 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz
Channel Bandwidth: 2.4GHz Supports 20MHz 5GHz Supports 80MHz
Security: WPA-PSK, WPA2-PSK, WPA3-Personal
Transmission Rate: 4GHz Max. Rate Support: 11b_11M,11g_54M, 11n_MCS7_20M,11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M,11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M
Output Power: (EIRP) 20 dBm
Antenna Gain: [email protected],[email protected]
Operating Conditions: -10°C to 45°C ( -14 °F to 113 °F ) Humidity 95% or less (non-condensing)
Power Consumption: 8W max
Power Supply: DC 5V/2A
IR Range: MAX. 10 meters (32.81ft)
Brand | |
---|---|
Product Categories | Cameras |
Works with | Alexa, Google Assistant |
