Description

Resolution Dual: 2K+ Resolution

Image Sensor: 1/3″ Progressive Scan CMOS

Shutter Speed: Self-adaptive shutter

Fixed Lens: [email protected] , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)

PT Lens: [email protected] , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)

Lens Mount: M12

Day & Night: IR-cut filter with auto-switching

DNR: 3D DNR

WDR Digital: WDR

Video Compression: H.264/H.265

Video Bit Rate: Adaptive bit rate.

Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection

Wi-Fi Pairing: AP paring

Protocol: EZVIZ cloud proprietary protocol

Interface Protocol: EZVIZ cloud proprietary protocol

Max. Resolution: 2560 × 1440

Frame Rate: Max:30fps; Self-Adaptive during network transmission

Storage: Micro SD card slot (Max. 512G)

Power: TYPE-C

Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Standard: IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax

Frequency Range: 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz

Channel Bandwidth: 2.4GHz Supports 20MHz 5GHz Supports 80MHz

Security: WPA-PSK, WPA2-PSK, WPA3-Personal

Transmission Rate: 4GHz Max. Rate Support: 11b_11M，11g_54M, 11n_MCS7_20M，11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M，11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M

Output Power: (EIRP) 20 dBm

Antenna Gain: [email protected]，[email protected]

Operating Conditions: -10°C to 45°C ( -14 °F to 113 °F ) Humidity 95% or less (non-condensing)

Power Consumption: 8W max

Power Supply: DC 5V/2A

IR Range: MAX. 10 meters (32.81ft)
