Description

Image Sensor: 1/2.8″ Progressive Scan CMOS

Shutter Speed: Self-adaptive shutter

Lens: 4mm@ F1.6, viewing angle: 49° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm@ F1.6, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal)

PT Angle: Pan: 350°, Tilt: 80°

Minimum Illumination: 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

Lens Mount: M12

Day & Night: IR-cut filter with auto switch

DNR: 3D DNR

WDR: Digital WDR

Black & White Night: 30m / 98ft

Max Resolution: 2304 × 1296

Frame Rate: Max: 30fps; Self-Adaptive during network transmission

Video Compression: H.265 / H.264

H.265 Type: Main Profile

Video Bit Rate: Ultra-HD; Hi-Def; Standard. Adaptive bit rate.

Audio Bit Rate: Self-Adaptive

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Smart Alarm: AI-Powered Human Shape Detection

Auto Tracking: Supports

Customized Alert Area: Supports

Two-way Talk: Supports

Preset Locations: Supports

General Function: Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Local Storage: Supports MicroSD Card (Up to 512 GB)

Operating Conditions: -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)

IP Grade: Weatherproof Design

Power Supply: DC 12V/1A, Supports PoE power supply

Power Consumption: MAX. 12W
