Description

Image Sensor: 1/2.7″ Progressive Scan CMOS

Shutter Speed: Self-adaptive shutter

Lens: 4mm@ F1.6, viewing angle: 48° (Vertical), 91° (Horizontal), 108° (Diagonal) 6mm@ F1.6, viewing angle: 30° (Vertical), 56° (Horizontal), 66° (Diagonal)

PT Angle: Pan: 350°, Tilt: 80°

Minimum Illumination: 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

Lens Mount: M12

DNR: 3D DNR

WDR: Digital WDR

Black & White Night: 30m / 98ft

Max Resolution: 2880*1620

Frame Rate: Max:30fps; Self-Adaptive during network transmission

Video Compression: H.265 / H.264

H.265 Type: Main Profile

Video Bit Rate: Ultra-HD; Hi-Def; Standard. Adaptive bit rate.

Audio Bit Rate: Self-Adaptive

Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth: Supports 20MHz

Security: WPA-PSK/WPA2-PSK

Transmission Rate: 11b 11 Mbps, 11g 54 Mbps, 11n: 72 Mbps

Wi-Fi Pairing: AP paring

Protocol: EZVIZ Cloud Proprietary Protocol

Interface Protocol: EZVIZ Cloud Proprietary Protocol

Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Smart Alarm: AI-Powered Human / Vehicle Shape Detection

Auto Tracking: Supports

Customized Alert Area: Supports

Two-way Talk: Supports

General Function: Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Local Storage: Supports microSD Card (Up to 512 GB)

Operating Conditions: -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)

IP Grade: Weatherproof Design

Power Supply: DC 12V/1A

Dimensions: 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch)

Packaging Dimensions: 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch)

Net Weight: 539.7g; With Package: 823.6g For EU Standard Version
